WYRESTORM CAB-IR-LINK

The WyreStorm CAB-IR-LINK IR integration cable provides integrators with a simple 2-way IR integration between WyreStorm products and any mainstream control system.

Simply plug the CAB-IR-LINK cable from the IR emitter output of any control system to the IR RX port of a WyreStorm matrix or extender set to achieve seamless control system compatibility and integration.

CONTROL SYSTEM BRIDGE

Literally “bridging” the gap between the control system and the distribution system, the CAB-IR-LINK is an essential part of any installers arsenal. Gone are the days of stripping back pre-moulded TRS cables to carry IR control signals.

LONG CABLE IDEAL FOR RACK INSTALLS

At 2m/74”, the CAB-IR-LINK is long enough to meet the requirements of the neatest of rack installers, enabling it to be laced neatly between the control system and the distribution system.

AUTO-SENSING COUPLER

Not just another dumb jack cable, the CAB-IR-LINK has a built-in circuit that will auto-sense incoming voltage & polarity and convert it to a signal suitable for connection to WyreStorm matrix or NetworkHD system.

3-POLE – 2-POLE CONVERSION

The CAB-IR-LINK has been designed with ease of use and the installer in mind. A 2-pole (mono) TRS jack is fitted to the end designed to connect to the IR emitter output of a control system and the 3-pole (stereo) end is designed to connect to the IR-RX input on a WyreStorm matrix or NetworkHD encoder.

FEATURES

• Compatible with most leading control systems, including: Control4, Crestron, AMX, Niles, RTI, Bitwise and WyreStorm Enado
• 1.2m (length) mono-stereo IR integration cable*
• Auto-sensing polarity
• Automatically adjusts for 5v or 12v control bus
• Tip-VCC 5V, Ring-Signal, Sleeve-Ground
• 3.5mm gold plated stereo plug

*Not suitable for use with jack extension leads
